Funksje fan kommersjeel Galv.Bow ShackleEurope -type
Material：Q235
Forged Steel
Surface Treatment：Selfkleur, Pleatst sink, Hot dip dalvanisearre,
Trivalent ferchroomzink, poedercoating
Kommersjele Galv.Bow Shackle Eigenskip
Europa type
Material：Q235
Forged Steel
Surface Treatment：Selfkleur, Pleatst sink, Hot dip dalvanisearre,
Trivalent ferchroomzink, poedercoating
Kommersjele Galv.Bow Shackle Spesifikaasje
| Grutte | D | d | B | H | R | SWL |
| mm | mm | mm | mm | mm | mm | tonnen |
| 5 | 5 | 5 | 10 | 19.5 | 15 | 0.08 |
| 6 | 6 | 6 | 12 | 24 | 18 | 0.1 |
| 8 | 8 | 8 | 16 | 32 | 24 | 0.2 |
| 10 | 10 | 10 | 20 | 40 | 30 | 0.32 |
| 11 | 11 | 11 | 22 | 44.5 | 33 | 0.4 |
| 12 | 12 | 12 | 25 | 49 | 36 | 0.52 |
| 14 | 14 | 14 | 28 | 59 | 42 | 0.65 |
| 16 | 16 | 16 | 32 | 64 | 48 | 0.8 |
| 18 | 18 | 18 | 36 | 71 | 54 | 1 |
| 20 | 19 | 20 | 38 | 80 | 60 | 1.1 |
| 22 | 22 | 22 | 44 | 85 | 66 | 1.5 |
| 25 | 25 | 24 | 50 | 100 | 75 | 2.1 |
| 28 | 28 | 27 | 56 | 116 | 86 | 3 |
| 32 | 32 | 33 | 64 | 129 | 96 | 3.5 |
| 38 | 38 | 39 | 76 | 151 | 114 | 5 |
